DESCRIPTION
The ARC-656 is a compact and portable stud welding power supply capable of welding studs thru 1/2" diameter reduced weld base.  The power supply which operates on three phase power produces a smooth, stable welding arc.  The front panel digital display indicates the weld time which is infinitely adjustable for preciseness and repeatability
The expanded time range provides fine adjustment of weld time for special short cycle applications such as welding to thin materials.

  DESCRIPTION
The ARC-800 is a compact and portable stud welding power supply capable of welding studs through 1/2" diameter weld base.  The power supply which operates on single phase power has the added feature of weld current regulation that improves stud welding consistency.  Both the weld time and weld currant are infinitely adjustable for preciseness and repeatability.
A specially designed electronic gun control circuit has been incorporated to increase overall reliablity.

       DESCRIPTION
The ARC-1200 is a compact and portable stud welding power supply capable of welding studs thru 5/8" diameter weld base.  The fully regulated power supply which operates on three phase power produces a smooth, stable welding arc.  Both the weld time and weld current are infinitely adjustable for preciseness and repeatability.
For maximum flexibility the weld time can be switched between two ranges.  The expanded short time range provides fine adjustment of weld time for special short cycle applications such as welding to thin materials.

   DESCRIPTION
The ARC-1850 is a fully regulated stud welding power supply that is available in a single or dual gun version. Both versions have the constant output feature that allows the unit to be used as a power source that can operate external stud welding control units.  Stick welding and Arc air gouging processes are available only as an option.  An added feature in the ARC-1850 is the ability to dial in the desired weld time and weld current before even making a weld.  By selecting the setup mode, the weld time and current can be adjusted and displayed on the front panel digital meters.  It is capable of welding studs from 12ga to 7/8" diameter with preciseness and repeatability.

        DESCRIPTION
The ARC-3000 is a fully regulated stud welding power supply that is available in a single or dual gun version. Both versions have the constant output feature that allows the unit to be used as a power source that can operate external stud welding control units.  An added feature in the ARC-3000 is the ability to dial in the desired weld time and weld current before even making a weld.  By selecting the setup mode, the weld time and current can be adjusted and displayed on the front panel digital meters.It is capable of welding studs from 1/4" to 1-1/4" diameter with preciseness and repeatability.
